CX3701 Short Depth Silent NAS
CX3701Short Depth Silent NAS
  • 10x trayless 3.5" SATA or SAS HDD mounts via captive SFF-8482 adapters
  • Magnetically attached front panel, locking mechanism for retaining HDDs
  • Two slot cutouts for single PCIe card; GPU, NIC, HBA, or RAID card
  • Mini-ITX motherboard, SFX or SFX-L power supply
  • 4x internal 2.5" SSD mounts for cache and boot drives
  • 2x 120mm exhaust fans for silent airflow, washable front dust filter
  • Designed and Manufactured in the USA by Sliger with US materials
Front Panel Color




BUSINESS CUSTOMERS: Custom branded front panels are available!
Services include custom powder coating of any color on Prismatic Powders, modified vent patterns, custom laser cutouts, and full color screen printing (including gradients). Please contact sales@sliger.com to discuss your requirements. A minimum order quantity (MOQ) of 10 units is required.
Rack Slides
Installation instructions for our CX/PM Series rack slides are available here.
*Indicated rack slides may ship in a seperate shipping box from the case itself.
120mm Fans
* Fan mounting screws and 30cm fan wire extension cables are included.
Add To Cart
FREE SHIPPING (US ONLY)
IN STOCK
Orders for CX3701 are currently shipping in 1-10 business days based on order quantity and current production availability. Contact us if you need expedited / same day order processing.
Order Terms & Conditions
5% CANCELLATION FEE
Due to changes in refund policies from PayPal and Amazon, all order cancellations are now subject to a 5% order cancellation fee.
Order Cancellations & Returns

Technical Specifications

SAS Expansion

Direct Attached Storage (DAS)

JBOD Enclosure

RAID Enclosure
Motherboard
  • Mini-ITX (170mm × 170 mm) [6.7" × 6.7"]
  • NOTE: Motherboard mounting tray can be slid out of case to simplify assembly and maintenance
CPU Air Coolers
CPU Liquid Coolers
  • 1x 92mm liquid cooler (Asetek 645LT) with 120mm to 92mm adapter
  • 92mm AIO to 120mm fan adapter is a 3D printed part
Fan Mounting
  • Rear
  • 1x 120mm fan, up to 38mm thick
  • Side
  • Single Slot PCIe Card: 1x 120mm x 25mm fan
  • Dual-Slot PCIe Card: 15mm thick fan recommended
  • Fan brackets are baffled from venting to reduce noise levels and improve airflow
GPU / PCIe Cards
  • 2x full height PCIe card slot cutouts
  • Maximum card height: 115mm
  • Maximum card length: 185mm,
  • If using a dual slot PCIe card, such as a GPU, you must use a slim (15mm thick) 120mm fan on the side vent
Storage
  • Ten(10) 3.5" SAS or SATA Hard Drive Disks
  • Case includes 10x SATA/SAS SFF-8482 male to SATA female adapters (preinstalled in case)
  • 4x shoulder screws attached to 3.5" HDDs
  • These shoulder screws guide HDDs through slots and align the drive to a backplane mounted SATA to SATA adapter
  • User must connect SATA data and power cables on inside of case to these SATA to SATA adapters
  • Case has a locking mechanism and key, as well as thumb screws, to secure drives
  • Case also includes two(2) SATA power distribution cables (1x SATA power male to 5x SATA power female)
  • Case does NOT include any data cables
  • Hot-swap support can depends on your HBA / RAID card, motherboard, and OS.
  • Please note that connecting a SAS drive to a SATA port will operate as SATA.
  • A SAS controller can control SATA drives, but a SATA controller cannot control SAS drives.
  • Four(4) 2.5" SSD/HDD mounting points (behind power button and USB front panel area)
Front Panel I/O
  • 1x USB C 10Gbps Port
  • 2x USB 3.0 Ports
  • 1x Momentary Switch / Power Status LED (Ring Shape, White)
Power Supply
  • SFX or SFX-L
Material
  • Chassis
  • ASTM-A-653 G30 Zero Spangle 20 Gauge Galvanized Steel
  • Front Panels
  • ASTM-A-653 G30 Zero Spangle 18 Gauge Galvanized Steel
  • Rack Ears
  • ASTM-A-653 G30 Zero Spangle 14 Gauge Galvanized Steel
Finish
  • Outdoor architectural grade polyester expoxy blend powder coat
  • Unpainted chassis, panels, or parts available on request (for DIY paint jobs)
  • Custom powder coat finishes are avaialble, additional labor/material charges and 10 unit MOQ will apply.
Branding
  • Case is unbranded on interior and exterior of chassis.
  • Optional logo screen printing (full color) on front panel for business customers, MOQ 10 units
  • Custom logo requires a one time design fee of $200 to create proofs and output files
Outside Dimensions
  • 14.89" x 17.00" x 3U (5.22") [DxWxH]
  • 378mm x 432mm x 132.5mm [DxWxH]
Weights
  • Chassis
  • Rack Slide Kits
  • Packaging Materials (Box, Tape, Foam Corners)
Shipping Box Dimensions
  • 21" x 19" x 9"
  • Double Wall
Rack Rails
  • Sliger PM-Series Ball Bearing Slides
  • iStarUSA TC Series
  • General Devices C300-S Series
Warranty
  • Case
  • 5 Year Warranty [Chassis, USB cables, Power Button, SATA Adapters]
  • Liquid Coolers & Fans
  • 3 Year Warranty
  • Please see our warranty policy for additional conditions, exclusions, and limitations.
Homologation
  • HTS Tariff Code
  • 8473.30.00.02
  • Country of Origin
  • United States of America
Rev Control
  • 1.0 (7/25/23 - **/**/**)
  • Initial Release
